DSCI 522 Lecture 3

Customizing and Building Containers

Sky Sheng

😺 iClicker: How is your group collaboration going?

(A)

(B)

(C)

Source

Conda Recap: 🧐 How to…

Create a new conda environment
List all conda environments
Activate a conda environment
Deactivate a conda environment
Remove a conda environment
List all packages in a conda environment
Remove a package from a conda environment
Update a package in a conda environment
Update all packages in a conda environment
Share a conda environment with someone else
Create a conda environment from environment.yml file
Duplicate a conda environment

📜 Conda Cheat Sheet Part 1️⃣

Task	Command
Create a new conda environment	`conda create -n <env_name>`
Create with specific Python version	`conda create --name <env_name> python=3.11`
Create with packages	`conda create --name <env_name> numpy pandas`
List all conda environments	`conda env list` or `conda info --envs`
Activate a conda environment	`conda activate <env_name>`
Deactivate a conda environment	`conda deactivate`
Remove a conda environment	`conda env remove -n <env_name>`
List all packages in environment	`conda list`
Remove a package from current environment	`conda remove <package_name>`

📜 Conda Cheat Sheet Part 2️⃣

Task	Command
Update a package in current environment	`conda update <package_name>`
Remove a package in other environment	`conda remove -n <env_name> <package_name>`
Update a package in other environment	`conda update -n <env_name> <package_name>`
Update all packages in current environment	`conda update --all`
Share environment	`conda env export --from-history > environment.yml`
Create conda environment from `environment.yml`	`conda env create --file environment.yml`
Duplicate a conda environment	`conda create --name <new_env> --clone <old_env>`

📕 Command Line Notes

--name and -n are equivalent.
--file and -f are equivalent.
-p and --platform are equivalent, to specify the platform (e.g., linux-64, osx-arm64, win-64).
More command line review cheatsheet is here.

Conda-lock Recap

🔒 What are the commands for the following tasks?

Generate a general conda-lock file for all platforms
Generate a conda-lock file for a specific platform

📜 Conda-lock Cheat Sheet

Command	Output
#General file all platforms `conda-lock lock --file environment.yml`	`conda-lock.yml`
#General file for one platform (e.g., Linux) `conda-lock lock --file environment.yml -p linux-64`	`conda-lock.yml`
#Explicit lock file for one platform (e.g., Linux) `conda-lock -k explicit --file environment.yml -p linux-64`	`conda-linux-64.lock`
#Explicit lock file from `conda-lock.yml` `conda-lock render -p linux-64`	`conda-linux-64.lock`

🙀 `conda-lock.yml` VS `conda-linux-64.lock`?

Feature	`conda-lock.yml`	`conda-linux-64.lock`
Format	Unified YAML (multi-platform)	Explicit (single-platform)
Content	Structured metadata + dependencies for all platforms	Simple list of package URLs
File Size	Larger (contains all platforms)	Smaller (one platform only)
Installation	`conda-lock install --name <env_name> conda-lock.yml`	`conda create --name <env_name> --file conda-linux-64.lock`
Use case	Development across multiple platforms	Production deployment, Docker, single platform
Speed	Slightly slower (conda-lock processes it)	Fastest

Some data science conventions

🐍 Use snake_case for all folder & file names (lowercase + underscore)
Use Markdown for documentation.
- Need a review? Here is the markdown tutorial
yaml (.yml or .yaml) files for data storage and system configurations (NOT for documentation)
- YAML = Yet Another Markup Language
- No use of strict symbols (e.g., braces, square brackets)
- Use # for comments
- Python style indentation using whitespace (NOT TABS)
- JSON is subset of YAML. JSON file can be parsed by a YAML parser.

🚢 Docker Recap

⚠️ Command lines are very sensitive to whitespace and quotation marks!

docker run \
    --rm \
    -p 8788:8787 \
    -e PASSWORD="apassword" \
    rocker/rstudio:4.4.2

🏷️ Don’t use the TAG latest for the image, use the specific version tag instead.
Docker cheatsheet is available in textbook

We don’t like manual work!

Source: Minions movie

🤩 `docker-compose.yml` file comes to the rescue!

services:
  analysis-env:
    image: rocker/rstudio:4.4.2
    ports:
      - "8789:8787"
    volumes:
      - .:/home/rstudio/project
    environment:
      PASSWORD: password
    deploy:
      resources:
        limits:
          memory: 5G

😳 But how to use `docker-compose.yml`?

Launch the container: docker compose up
Stop the container: type Cntrl + C in the terminal where you launched the container, and then type docker-compose rm
Read more in the textbook here

Today’s topic: Let’s build our own container!

Docker images for RStudio, VSCode, and Cursor!

Daniel has kindly created this tutorial on how to build docker image for R environment managed by renv: docker-renv
Sky has created this tutorial for how to build docker image for VSCode & Cursor: docker-vscode-cursor

Command line using `docker-compose.yml` file

Code we run in class: `docker-compose.yml` practice

Step-by-step instructions:

# 1. Please first `cd` to a local folder of your choice, don't put all files in your home directory!
# Example `cd` command:
cd /Users/skysheng/Desktop/github/dsci522

# 2. make a new folder called `demo_docker` (or any other name you like)
mkdir demo_docker

# 3. move into that folder we just created
cd demo_docker

# 4. create a docker-copose.yml file using nano
nano docker-compose.yml

Code we run in class: `docker-compose.yml` practice

Copy and paste the following code into the docker-compose.yml file. Local port is set at 8789, password is set to password, username is rstudio.

services:
  analysis-env:
    image: rocker/rstudio:4.4.2
    ports:
      - "8789:8787"
    volumes:
      - .:/home/rstudio/project
    environment:
      PASSWORD: password
    deploy:
      resources:
        limits:
          memory: 5G

You can also create this file using Graphical user interface (GUI) like VSCode.
If you used nano to create this file, you need to press Cntrl + X to attempt exit, by default it will ask you to save the file. Press Y and then press Enter to save the file.

Code we run in class: `docker-compose.yml` practice

# 6. Print out the content of the file to make sure it is correct.
cat docker-compose.yml

# 7. Launch the container using docker compose files.
docker compose up

After the container is launched, your terminal will be hanging. You can open your browser and go to http://localhost:8789 to access RStudio.
To stop the container, you need to type Cntrl + C in the terminal where you launched the container, and then type:

# 10. Remove the container.
docker-compose rm

Command line creating `Dockerfile`

Code we run in class: `Dockerfile` practice

Step-by-step instructions:

# 1. Please first `cd` to a local folder of your choice, don't put all files in your home directory!
# Example `cd` command:
cd /Users/skysheng/Desktop/github/dsci522

# 2. make a new folder called `demo_docker` (or any other name you like)
mkdir demo_docker

# 3. move into that folder we just created
cd demo_docker

# 4. create a environment.yml file using nano
nano environment.yml

Code we run in class: `Dockerfile` practice

Copy and paste the following code into the environment.yml file.

name: my_env
channels:
- conda-forge
dependencies:
- conda-lock=3.0.4
- pandas=2.3.3
- pandera=0.26.1
- pip=25.3
- python=3.11.14
- pip:
  - deepchecks==0.19.1

You can also create this file using Graphical user interface (GUI) like VSCode.
If you used nano to create this file, you need to press Cntrl + X to attempt exit, by default it will ask you to save the file. Press Y and then press Enter to save the file.

Code we run in class: `Dockerfile` practice

# 6. Print out the content of the file to make sure it is correct.
cat environment.yml

Create a conda-lock file using the following command:

Macbook users with Apple Silicon chips will need to use the following command to create a explicit lock file for linux OS:

conda-lock -k explicit --file environment.yml -p linux-aarch64

Everyone else can use the following command:

conda-lock -k explicit --file environment.yml -p linux-64

Code we run in class: `Dockerfile` practice

Create a Dockerfile file using nano, or you can use GUI like VSCode.

# 8.Create a Dockerfile file using nano, or you can use GUI like VSCode.
nano Dockerfile

Code we run in class: `Dockerfile` practice

Copy and paste the following code into the Dockerfile file. We use jupyter minimal notebook image as an example, and copy the conda-lock file to the container.

Macbook users with Apple Silicon chips will need to use the following code:

FROM quay.io/jupyter/minimal-notebook:afe30f0c9ad8

COPY conda-linux-aarch64.lock /tmp/conda-linux-aarch64.lock

Everyone else can use the following code:

FROM quay.io/jupyter/minimal-notebook:afe30f0c9ad8

COPY conda-linux-64.lock /tmp/conda-linux-64.lock

Code we run in class: `Dockerfile` practice

Build the docker image locally using the following command:

# 10. Build the docker image locally, with the tag name `testing_cmds`.
# pay attention to the dot at the end of the command!
docker build --tag testing_cmds .

Code we run in class: `Dockerfile` practice

Run the docker image you just built using the following command:

Launch terminal only (Mac M4 chip you may run into bugs here):

docker run --rm -it testing_cmds ../../bin/bash

Launch interactive terminal on web browser:

docker run --rm -it -p 8888:8888 testing_cmds
